Construction - 3S Industry

The range of 3S INDUSTRY products & solutions for the construction industry includes Ladder Hoist, Trailer Lift, Tower Climber, Industrial Elevator, Transport Platform, Construction Hoist, Retractable Discharge Platform, Mast Climbing Work Platform and Electric Rope Hoist which are suitable for use across a range of construction applications.

Ladder Hoist

The Ladder Hoist is a customized portable solution for lifting various materials in limited space. It can stably and efficiently lift heavy materials to a designated height.

Model: MH03L250-expert
Rated load: 250 kg
Lifting speed: 30 m/min
Max. lifting height: 19 m

Trailer Lift

Trailer Lifts are high-altitude material hoisting equipment that can be used in a variety of scenarios, including construction, house repair, furniture and solar panel handling. They have features of simple operation, convenient transfer, and quick and efficient operation, which greatly improves the efficiency of material handling.

Model: 3S-YT836
Max. travel speed: 45 km/h
Rated load: 400 kg
Max. rail length: 36 m

Tower Climber

The Tower Climber is a battery-powered auxiliary lifting equipment, which can be used in tower crane, wind tower, high voltage tower, bridge tower detection, oil refinery, cooling tower, granary, storage warehouse and other fields.

Capacity: 1 person
Weight: 70 kg
Rated load: 150 kg
Dimensions: (380 × 560 ×1340) mm

Industrial Elevator

Industrial elevators are a general-purpose vertical transportation product that uses a rack and pinion drive. They can be used in a variety of applications, such as chimneys, bridge towers, hydroelectric power plants, and port machinery.

Max. number of persons: 24
Rated load: 2000 kg
Rated speed: 0-36 m/min
Motor power: 2×15 kW

Transport Platform

The Transport Platform is a versatile conveyance device used extensively in industrial production and construction sites, capable of carrying both passengers and cargo for elevation operations.

Model: 3S 2000H/HP
Rated load: 2000kg
Lifting speed: 24m/min
Max. height: 100m

Construction Hoist

The Construction Hoist is a crucial piece of lifting machinery used in the construction industry, providing vertical access for operators, materials, and equipment.

Model: 3S-450 SC 100/100
Rated load: 1000 kg
Speed: 0-35/0-46/0-54/0-63 m/min
Cage size (LxWxH)m: 3.2×1.5×2.3

Retractable Discharge Platform

The Retractable Discharge Platform is a temporary operating platform or frame built on the construction site for material turnover.

Model: CNH32
Maximum total load: 10t
Outer width: 3165mm
Inner width: 2500mm

Mast Climbing Work Platform

The platform is suitable for various exterior wall contour and can be applied in the fields of construction, maintenance, and cleaning.

Model: MCWP450-S
Load capacity: 1400 - 2300 kg
Lifting height: 200 m
Lifting speed: 8 m/min ± 10%

Electric Rope Hoist

An electric rope hoist is a light-duty, easy-to-install, and compact lifting appliance. It is intended to lift loads to specified height in a reliable and effective manner.

Model: RH-T250
Rated load: 250 kg
Lifting speed: 22 m/min - 28 m/min
Max. lifting height: 25 m/50 m

WHY CHOOSE 3S INDUSTRY CONSTRUCTION
PRODUCTS & SOLUTIONS

High Cost Performance

Leading R&D Capability

Excellent Quality Management System

Professional Global Service Capability
