产品中心

逃生+救援+培训

匀速缓降,安全可靠

该款逃生包是一种紧急高空下降和救援逃生装置,可应用于高空逃生、救援及培训演练。作业人员通过逃生包从较高位置沿绳索匀速下降至安全位置,也按照说明书要求对攀爬人员进行主动和被动救援。

Sosaf-2R型
Sosaf-3R型
(逃生+救援+培训)

Automatic Descent and Assisted Rescue

The Evacuation And Rescue Device is an essential safety device when working at height. In cases where regular descent via the wind turbine tower’s ladder or lift is not possible, the Evacuation And Rescue Device provides emergency descent and assisted rescue. With its bi-directional design, it enables the fully automatic, controlled evacuation of up to two people simultaneously. The dual-brake mechanism with active heat dissipation ensures reliable performance, even when descending heavy loads from great heights.

技术参数

自动防回转装置(实时锁止制动)

增加自动防回转装置在救援过程中实现实时制动,救援更省力。

自动防回转装置(实时锁止制动)

增加自动防回转装置在救援过程中实现实时制动,救援更省力。

01 / 02

SOSAF-3R



型号 Sosaf-2R Sosaf-3R
工作绳直径 9.6 mm 9.6 mm
下降速度 ~0.9 m/s ~0.9 m/s
设备重量 ( 不含绳 ) 2.5 kg 3.1kg
救援能力 1人 30-150 kg,提升65 m

2人 250 kg,提升10 m

2人 282 kg,提升10 m (紧急状态)
1人 30-150 kg,提升65 m

2人 250 kg,提升10m

2人 282 kg,提升10 m (紧急状态)

自动防回转(实时锁止制动)
下降载荷 1人150kg,单次下降高度500m

2人250kg,单次下降高度250mm

2人282kg,单次最大下降高度150m
本设备实际下降最大高度必须小于绳长。紧急情况下,最大救援负载可达 282kg 提升10m。 此种情况下,手动操控力和工作绳磨损均会增加。



型号 Sosaf-2R Sosaf-3R
认证 ANSI/ASSE, CE, CU-TR ANSI/ASSE, CE, CU-TR
静力绳符合标准 EN 1891 Type A EN 1891 Type A
连接器符合标准 EN362;锚点:EN795 EN362;锚点:EN795
执行标准 EN 341:2011/1A;

EN 1496:2017

ANSI/ASSE Z359.4-2013;

CAN/CSA-Z259.2.3:16
EN 341:2011/1A;

EN 1496:2017

ANSI/ASSE Z359.4-2013;

CAN/CSA-Z259.2.3:16
